Quelfire Fire Stop Compound

The QF2 Fire Protection Compound is a non-combustible compound manufactured from lightweight graded fire resisting aggregates, in organic binders and high-quality gypsum cements to give excellent fire resistance, strength and versatile workability.

The QF2 Fire Protection Compound is mixed on site with water and can be applied to both floors and walls. Once cured, QF2 will provide a load bearing and fire rated seal.

It expands slightly on curing (0.1%), to form a rigid seal and is also suitable for use in load bearing situations. Subsequent to installation it will accept further services penetrating the barrier without damage.

QF2 is supplied in 20kg bags which must be stored in dry conditions. Shelf life, in an unopened bag, is typically 12 months.

Features

• Fire Tested to BS 476-20 and BS EN1366-3
• Up to 4 hour fire rating
• Acoustic tested to 47dB
• Suitable for load bearing situations
• Expands slightly on curing to form a rigid seal
• The use of extensive shuttering is not necessary
• Can be used in conjunction with other Quelfire products such as Pipe Collar s and Quelcoil Intuwrap
• Ideal for service risers
• Suitable for use in concrete floors, hollow core slabs and steel profiled deck floor systems

• Installation Instructions
• Product DataSheet
• QF2-CF150-08-Plastic-Pipe-penetrating-a-rigid-floor-QWW
• QF2-HC150-01-Cable-penetrating-a-hollow-core-floor
• QF2-CF150-04-Insulated-Metal-Pipe-penetrating-a-rigid-floor
• Quelfire-QF2-Fire-Protection-Compound-Material-Safety-Data-Sheet-COSHH
• QF2-HC150-12-Sleeved-Gas-Pipe-penetrating-a-hollow-core-floor
• QF2-CF150-10-Metal-Pipe-penetrating-a-rigid-floor
